Fixed Frame Projection Screen
Sable Frame 2 Series
Sable Frame 2 SeriesSable Frame 2 Series in Boardroom
Sable Frame 2 Series Lifestyle Application
Sable Frame 2 Series Back Corner detail
Sable Frame 2 Series Aspect Ratios
Sable Frame 2 Series Home Application
Sable Frame 2 Series Sizes
Sable Frame 2 Series Home Application
Sable Frame 2 Series Home Application
Sable Frame 2 Series Front View
Sable Frame 2 Series Bottom Corner Detail
Sable Frame 2 Series Back Detail
Sable Frame 2 Series Edge Frame
Sable Frame 2 Series
Sable Frame 2 Series Hardware Kit
Sable Frame 2 Series Right Side View
Sable Frame 2 Series 2.35:1 Aspect Ratio
Sable Frame 2 Series Left Side View
The Sable Frame 2 Series uses Elite Screens’ ISF Certified CineWhite® UHD-B 1.3 gain material within a velveteen coated frame. CineWhite UHD-B provides extra gain for HDR content in a dark room environment. Installation brackets included that permit the frame to slide horizontally.
| Viewing Angle | 180° |
|---|---|
| Gain | 1.3 |
| Screen Material | |
| Compatible Projection | Ultra Short Throw, Short Throw, Standard "Long" Throw |
| Material Type | Matte White |
Screen Material
- ISF Certified CineWhite® UHD-B 1.3 Gain front projection material
- ISF Certified for accurate color reproduction
- Black Backing eliminates light penetration
- Outstanding picture quality at any viewing angle with no compromise in resolution or brightness
- Active 3D, 4K Ultra HD, and HDR Ready
- Elegant velvet covered frame absorbs projector overshoot and increases picture contrast
- Compatible with Ultra/Short and Standard throw projectors
(Check EliteProjector® Ultra-Short Throw Projector) - Available in the following range of diagonal sizes:
- 100″ – 200″ in 16:9 format
- 114″, 125″ and 144″ in 16:10 format
- 138″ and 158″ in 2.35:1 format
Design and Installation
- 2.4” width frame and is velvet coated
- Split-frame design facilitates lower shipping costs without sacrificing quality
- Easy to assemble and install in minutes
- Wall brackets allow screen to slide horizontally for properly centered installation
- Installation kit includes: Woods screws & anchors and Wall Brackets
Quality and Reliability
- 2-year limited warranty, and 3-year warranty for ENR-G – Education, Non-profit, Religious and Government/Military organizations
- Lifetime Tech Support by Elite Screens Professional Service Team through Email, Phone or Online Form.
Dimensions
- Dimensions Table – EN Type (PDF)
- Dimensions Table – M Type V2 (PDF)
- Frame Dimensions – M Type V2 (PDF)
- Packaging Dimensions Table (PDF)
- Dimensions Table (PDF) – Discontinued
User Guides
- User Guide – EN/H Type (PDF)
- User Guide – EN/H Type V2 (PDF)
- User Guide – M Type V2.2 (PDF)
- User Guide (PDF)
Others
Sable Frame 2 Series FAQ’s
While the frame structure and screen material performance remain the same between the version 1 and version 2 of the (Lunette, SableFrame,ezFrame) series, there are two main differences.
– Version 2 features a newly designed material that has a rubber-edge border (does not apply to AcousticPro materials) which makes installation a lot easier and a lot less time consuming.
– Version 2 comes with an installation kit that includes wood screws & improved dry-wall anchors, wall brackets, screwdriver, and a mallet.
Both of these new features help speed up the overall process of assembly and installation of your fixed frame projection screen.
The Sable Frame and ezFrame frame have different frame designs. The SableFrama has an Astragal (half round surface flanked by 2-flat sides) profile as opposed to the ezFrame’s standard (wedge or sloped-edgethe frames are different only to suit different aesthetic needs. Please see this PDF for an illustration of the differences. Both frames come in 16:9, 16:10, and 2.35:1 aspect ratios. Both are also available in Cinegrey, Cinegrey5d, Cinewhite™, Powergain, and AcousticPro1080P2. The ezFrame is different in that it is also 4:3 aspect ratio and it is available with AcousticPro1080P3 and WraithVeil(rear projection) screen material.
Elite Screens offers replacement materials for 4:3, 16:9, and 2.35:1 fixed frame screens.
Decoding the model number: ZR92WH1-M
ZR- Sable Frame / ezFrame Series Replacement Material
92= Diagonal Size of 92″
W= CineWhite
H= 16:9 Aspect Ratio (V= 4:3, Wide= 2.35:1)
-M = Screen Type
ZAR : Aeon Series Replacement Material
Z-SBSF : Sable Frame B2 Series Replacement Material
Shop links : Sable Frame / ezFrame Series Materials, Aeon Series Materials, Sable Frame B2 Series Materials
General Fixed Frame Screens FAQ’s
In addition to an appealing aesthetic appearance, the advantage of having a black velvet covered frame is to help absorb projector overshoot.
Center support bar for larger size fixed frame screens goes inside the top of the groove located on the back of the frame.
Elite Screens does not recommend attempting such an installation as in most cases it would not be possible. This is because the frame has to be lifted directly above and then placed down onto the brackets. The brackets will then latch onto the grooves of the frame and hold it in place. Mounting the wall brackets flush to the wall and ceiling would not provide the clearance needed for the frame to be lifted above the brackets. Elite Screens recommends the wall brackets be placed no closer than 4-6”(depending on the thickness of the frame) below the ceiling as that ditstance would give you the clearance needed to lift the screen above and then onto the brackets.
2-year limited warranty, and 3-year warranty for ENR-G – Education, Non-profit, Religious and Government/Military organizations
Lifetime Tech Support by Elite Screens Professional Service Team through Email, Phone or Online Form.
