Ceiling Ambient Light Rejecting Projection Screen
Sable Frame StarBright 9®
Newer or Similar Product
The Sable Frame StarBright 9® provides reference grade video performance in either a dark room or rooms with high levels of interior lighting. Instead of the image washout common with typical matte-white projection screens, the Sable Frame StarBright 9® blocks illumination from overhead or off-axis light sources for a bold, bright, crystal-clear image even in the most challenging spaces. When shown under optimal cinematic lighting conditions, the material lives up to its ISF certification by the world-renowned Imaging Science Foundation.
The projection surface is bordered by a 2.3” (59.4 mm) thick aluminum frame that is coated in hand-wrapped velvet. The StarBright 9® screen is a composite, multi-layer material designed to reject ambient light away from the viewer’s field of vision. This composite material eliminates the washout effect which destroys matte white imagery under bright room lighting conditions. The StarBright 9® material attaches to the frame using a spring and grommet construction that ensures perfect uniform flatness. In addition to absorbing overhead ceiling light, the StarBright 9’s black diffusion layer provides high-contrast performance to enhance color saturation, contrast and black level dynamic range.
| Product Weight | N/A |
|---|---|
| Overall Dims | N/A |
| Viewing Angle | 170° |
| Gain | 0.9 |
| Screen Material | |
| Compatible Projection | Standard "Long" Throw |
| Material Type | Ambient Light Rejecting (ALR/CLR®), Silver & Grey |
Screen Material
- StarBright 9 material has a wide viewing angle that reflects a bright image across the entire surface for superior off-axis performance
- Active micro-structural filters absorb 95% of ambient light from above and below
- Diffusion layers enhance color contrast and black/white dynamic range performance
- Wide diffusion uniformity across the entire screen surface without color shift, texture, shimmer, hot-spotting, dark corners and other distracting artifacts
- Scratch-resistant material is easy to clean
- 4K/8K Ultra HD, HDR Ready for high resolution projectors and content
- Certified by the Imaging Science Foundation (ISF) for accurate color points, dynamic range, and color temperature
- Available in diagonal sizes: 106” and 122” in 16:9 or 156” in 2.40:1 aspect ratio
Design & Installation
- 2.3” wide aluminum frame with hand-wrapped velveteen surface provides an elegant finish while absorbing projector overshoot
- Spring and grommet attachment system allows for an easy installation with a clean, smooth projection surface
- Lightweight split-frame design is cost effective for shipping and provides easy access to install sites
- Assembles and installs in minutes
- Sliding wall mounts ensure precision on-axis alignment
Quality and Reliability
- 2-year limited warranty, and 3-year warranty for ENR-G – Education, Non-profit, Religious and Government/Military organizations
- Lifetime Tech Support by Elite Screens Professional Service Team through Email, Phone or Online Form.
Do not install projector at an angle that is greater than 5 degrees off the vertical axis from the screen. The ambient light filtration layer in the material is designed to absorb light rather than reflect it.
Sable Frame Series FAQ’s
While the frame structure and screen material performance remain the same between the version 1 and version 2 of the (Lunette, SableFrame,ezFrame) series, there are two main differences.
– Version 2 features a newly designed material that has a rubber-edge border (does not apply to AcousticPro materials) which makes installation a lot easier and a lot less time consuming.
– Version 2 comes with an installation kit that includes wood screws & improved dry-wall anchors, wall brackets, screwdriver, and a mallet.
Both of these new features help speed up the overall process of assembly and installation of your fixed frame projection screen.
The Sable Frame and ezFrame frame have different frame designs. The SableFrama has an Astragal (half round surface flanked by 2-flat sides) profile as opposed to the ezFrame’s standard (wedge or sloped-edgethe frames are different only to suit different aesthetic needs. Please see this PDF for an illustration of the differences. Both frames come in 16:9, 16:10, and 2.35:1 aspect ratios. Both are also available in Cinegrey, Cinegrey5d, Cinewhite™, Powergain, and AcousticPro1080P2. The ezFrame is different in that it is also 4:3 aspect ratio and it is available with AcousticPro1080P3 and WraithVeil(rear projection) screen material.
Elite Screens offers replacement materials for 4:3, 16:9, and 2.35:1 fixed frame screens.
Decoding the model number: ZR92WH1-M
ZR- Sable Frame / ezFrame Series Replacement Material
92= Diagonal Size of 92″
W= CineWhite
H= 16:9 Aspect Ratio (V= 4:3, Wide= 2.35:1)
-M = Screen Type
ZAR : Aeon Series Replacement Material
Z-SBSF : Sable Frame B2 Series Replacement Material
Shop links : Sable Frame / ezFrame Series Materials, Aeon Series Materials, Sable Frame B2 Series Materials
General Fixed Frame Screens FAQ’s
In addition to an appealing aesthetic appearance, the advantage of having a black velvet covered frame is to help absorb projector overshoot.
Center support bar for larger size fixed frame screens goes inside the top of the groove located on the back of the frame.
Elite Screens does not recommend attempting such an installation as in most cases it would not be possible. This is because the frame has to be lifted directly above and then placed down onto the brackets. The brackets will then latch onto the grooves of the frame and hold it in place. Mounting the wall brackets flush to the wall and ceiling would not provide the clearance needed for the frame to be lifted above the brackets. Elite Screens recommends the wall brackets be placed no closer than 4-6”(depending on the thickness of the frame) below the ceiling as that ditstance would give you the clearance needed to lift the screen above and then onto the brackets.
